Walbro 535 LPH High-Flow In-Tank Fuel Pump Designed for E85 and Gasoline – Universal Installation

Description

NOTE: THIS IS A UNIVERSAL FUEL PUMP, NOT DIRECT FIT FOR AN SPECIFIC MODEL AND WILL REQUIRE ADDITONAL MODIFICATION FOR INSTALL.

New DCSS 39/50 High-Performance Pump – F90000295:
– Highest flow in-tank brushed fuel pump offering from TI Automotive / Walbro
– No Internal check valve – ideal for racing applications to build oil pressure prior to start-up
– Featuring award winning DCSS technology
– E85 compatible
– High-pressure relief setting – supports supercharger and turbo applications
– Capable of supporting 900+HP at 60PSI naturally aspirated applications
– Complete Pump and kit combination – TCD495
Fuel: GAS & E85
Horsepower: 900+ at 60PSI, naturally aspirated applications
Over All Pump Length: 131mm
Main Housing Diameter: 39mm
Lower Housing Diameter: 50mm
Fuel Inlet Diameter: 11mm OD
Fuel Outlet Diameter: 11mm OD
Flow Rate: 535LPH at 40psi
Test Voltage: 13.5 Volts

Note: Pump does NOT have a check valve
